ARCPANEL Roof Systems – Residential roofing for your home

Residential Roofing

ARCPANEL Roof Systems – The all in one insulated roof panel system with the ultimate design flexibility to create a look and feel just for you and your home. Australian made with product warranty up to 20 years for peace of mind.

ARCPANEL roof systems benefit from high structural strength and can achieve spans up to 12.5m and cantilever overhangs up to 4.5m.

Create architectural features, simplicity and environmental benefits all in one easy to install versatile roof system.

ARCPANEL – Fast & simple to install, the all-in-one roof, insulation and ceiling solution

The ARCPANEL is a pre-fabricated structural insulated panel, available in a range of contemporary profiles (corrugated & trapezoidal) comprising of Colorbond® steel sheeting, which is bonded to both sides of a profiled fire retardant EPS or PIR core.Each ARCPANEL is formed using the selected profile (corrugated & trapezoidal) on both roof and ceiling side of the panel.

The panel’s top and bottom sheets are pre-finished in an extensive range of Colorbond® colours.

ARCPANEL Roof systems are compatible with most architectural designs as multiple configurations are available across the range. Available in straight, curved and/or multi-curved panels.

Up to 20 years warranty available – for peace of mind.*

Firetek PIR – BAL 40 Rated Roof Panel

The ARCPANEL roof system featuring a PIR insulation core (Firetek) was introduced in response to the mandatory bushfire attack level ratings; a prefabricated insulated panel that consists of two single Colorbond® sheets which are bonded to a fire-retardant PIR core.

Firetek PIR roof panels have excellent thermal insulation and are especially suitable for use in bushfire prone areas. BAL 40 – tested for bushfire and fire resistance (AS 3959). R-value up to 6.6 allows you to maximise energy efficiency, reduce energy costs and your carbon footprint.

EPS – FR Roof Profiles

Roof Panel Profiles

PIR BAL 40 fire rated roof panel

Firetek PIR Roof Profiles

Visit our Project Gallery to view a range of completed projects

Interested in transforming your building into a contemporary architectural design? Our gallery features a range of projects that showcase the ARCPANEL Roof System in residential applications.

Patio Roofing & BBQ Area Roofing

Custom Panel

Drumkerin

Residential

Beach House

Residential Roof Project

Quad Residential

Multi-Residential Roof

Sunninghill House

Residential Roof Project

Contemporary Roof Panels

Patio Roofing

Noosa River

Outdoor Entertaining Roof

Timber Deck Roof

Insulated Patio Roof

Need help selecting a roof for your project?

Call ARCPANEL for assistance on 1300 200 004 and speak with one of our experts.

Contact ARCPANEL

Fully customised, insulated roofing solutions

Custom manufactured to your architectural design requirements, innovative ARCPANEL insulated panel systems allow you to design without boundaries, significantly reducing structural elements & labour components, whilst providing excellent thermal properties that reduce energy demands for the life of the building.

Superior Warranty

Up to 20 years warranty available – for peace of mind.*
Cyclone Rated Roof System

Cyclone Rated

Cyclone rated up to C4. ARCPANEL roof panels are tested in accordance with NCC/BCA requirements.
Fire Rated Roof System

Group 1 Fire Rated

Certified up to Group 1 fire rating in accordance with the fire hazard properties of NCC/BCA.
Large span available

Superior Span

Industry leading spans of up to 12.5m, cantilevers of up to 4.5m and quick to install.

Fast Track Projects

Reduce costly structural items & labour components, saving time and money.
Drafting Service

Drafting Service

Comprehensive drafting service to ensure your roof system is manufactured to the correct requirements.
Corrosive & Marine Solution

Marine Solutions

Roofing options suitable for marine or corrosive environments with warranties up to 20 years.
Exceptional Customer Service

Exceptional Service

Experienced customer service teams provide assistance during installation if required.
High Thermal rating

High Thermal Rating

R-value ratings up to R6.6. An ARCPANEL roof can reduce heating and cooling requirements.
Sustainable Construction

Sustainable

Prefabricated systems made to order can reduce construction time, waste and embodied energy.

ARCPANEL Roof System Benefits

  • Pre-finished high durability & low maintenance
  • Reduction of costly structural items & labour components, saving time & money
  • Superior low pitch – suitable for roof pitch 2°+ applications
  • Achieve up to 12.5 metres unsupported spans – reduce expensive support structures e.g. roof trusses & support beams
  • Large cantilevers of up to 50% of the actual back span can be achieved (dependant on the design)
  • Pre-finished top and bottom sheet – extensive range of Colorbond colours available
  • Compatible with most architectural designs as multiple configurations are available across the range
  • Cyclone tested up to C4 in accordance with NCC/BCA
  • ARCPANEL roof panels are available in Colorbond®, Ultra, Stainless, Metallic, Matt, Zinc/Galv. Roof panels are also available in Magnaflow®
  • Rapid installation makes the ARCPANEL roof panel a clear winner over traditional roof construction
  • Fire rated up to Group 1 – roof and wall lining
  • Superior thermal – ratings up to R6.6 reduce heating & cooling demand & cost for the life of the building

Available Roof Types

Straight Roof Profile

Straight Roof

Straight panels can be manufactured up to 20 metres in length. Longer lengths can be achieved, contact us for further details.

Curved Roof Profile

Curved Roof

Curved panels are custom manufactured to suit your design requirements (minimum radii 2.5 metres).

Multi-Curved Roof Profile

Multi-Curved Roof

Multi-curved panels are custom manufactured to suit your design requirements (minimum radii 2.5 metres).

Bull-Nose Roof Profile

Bull-Nose Roof

Bull-nose panels can be manufactured to suit a bull-nose radii of 600mm, 750mm and 900mm. Bull-nose panels can be manufactured in lengths up to 12 metres.

Product Colour Range


Colour swatches are provided as an indication of colour only and may not be an actual representation of colour. We recommend checking your chosen colour against an actual sample of the product before purchasing.

Corrosion resistant options available for coastal applications – please contact us for more details.

Tested, Certified and Trusted

ARCPANEL Roof Systems are fully certified and engineered systems. Certification provides you with peace of mind that your roof system is Building Code compliant when choosing a ARCPANEL roof for your project.Arcpanel products conform to the NCC (National Construction Code) as they meet specific performance requirements for the building application.

Need help selecting a roof for your project?

Call ARCPANEL for assistance on 1300 200 004 and speak with one of our experts.

Contact ARCPANEL

Arcpanel – Our range of industry leading products

Formerly known as Ritek Roof Systems, ARCPANEL is an Australian owned company that manufactures innovative roof panel systems; providing a value added alternative to conventional construction methods.
Custom Panel

Custom Panel

Designed for roof pitch 5°+ roofing applications. The Custom Panel can be made in straight, curved, multi-curved & bullnose configurations. Thermal performance up to R6.5.

Find out more

Ecotek Panel

Ecotek Panel

Designed for both commercial and residential applications where low pitch 2°+ roofing applications are required. Ecotek Panel can be made straight & curved**.

Find out more

Firetek PIR Panel

Firetek PIR Panel

BAL 40 tested & certified, the Firetek PIR Panel is suited to both residential and commercial applications. Available in a range of profiles & configurations. Thermal performance up to R6.6.

Find out more

Aquatek Panel

For aquatic and corrosive environment applications both residential and commercial. Available in a range of profiles & configurations. Thermal performance up to R6.6.

Find out more

Smartek Panel

Smartek Panel

Contemporary in appearance, the Smartek Panel is formed using the Smartspan® profile on both roof and ceiling side of the panel. Suitable for roof pitch 2°+ applications.

Find out more
