Designed for roof pitch 5°+ roofing applications, with superior span and cantilever capabilities
The ARCPANEL Custom Panel can achieve significant cantilevers, in some applications up to half the actual back span and this unique system eliminates the need for complex, expensive roof structures. The lightweight ARCPANEL panels are easily handled on site, achieving faster, lower cost installation.
Visit our gallery to view a range of ARCPANEL projects
Need help with any of our products?
Call ARCPANEL for assistance on 1300 200 004 or send an enquiry via our contact page.
Key Features & Benefits
- Suitable for roof pitch 5°+ applications
- Panel lengths 1.2m – 20m available. Panels can be joined to achieve longer runs, contact us for details
- Achieve up to 12.5m unsupported spans – reduce expensive support structures e.g. roof trusses & support beams
- Corrugated profile is used on both sides, reducing the need for ceilings and internal painting
- Pre-finished – extensive range of Colorbond® colours
- Straight, curved or multi-curved configurations, suitable for most architectural designs
- Dependant on the design, cantilevers of up to half the actual backspan can be achieved
- Suitable for use in cyclonic wind conditions
- ARCPANEL Custom roof panel is available in Colorbond®, Colorbond® Ultra, Stainless Steel, Zincalume® & Xtreme Magnaflow
- Rapid installation makes the ARCPANEL Custom roof panel a clear winner over traditional roof construction
- Fire rated to Group 1 – roof and wall lining material
- Superior standard thermal ratings up to R6.5 are achieved using the ARCPANEL Custom roof panel
- Panels meet the requirements for live and concentrated imposed loads for roofs not accessible except for normal maintenance as per AS1170.1:2002
- Bushfire attack level BAL-12.5 to BAL-40
- Can be customised to your requirements.
- Warranty period of up to 20 years, for peace of mind.
Panel Applications
Straight Roof
Curved Roof
Multi-Curved Roof
Bull-Nose Roof
Panel Dimensions
| Corro/Corro | 75 | 85 | 100 | 125 | 140 |
| 160 | 175 | 200 | 250 |
Overall thickness in mm
Product Summary
| Panel Profile (Top/Bottom) | Corro/Corro |
|---|---|
| Min Roof Pitch | 5 deg |
| Max Span | 12.5m |
| Max Cantilever | 4.5m |
| Max Length | 20m |
| Min Length | 1.2m |
| Min Curved Radius | 3.0m |
| Thickness | 75 to 250mm |
| R-Value | R1.7 to R6.5 |
| Cyclonic Rating | C4 |
| BAL Rating | BAL 40 |
| Group Fire Rating | Group 1 |
| Xtreme Option | YES |
Tested, Certified & Trusted
Arcpanel products conform to the NCC (National Construction Code) as they meet specific performance requirements for the building application.
Panel Colours
Colour swatches are provided as an indication of colour only and may not be an actual representation of colour. We recommend checking your chosen colour against an actual sample of the product before purchasing.
Corrosion resistant options available for coastal applications – please contact us for more details.
Custom Panel Technical Documentation
Hard copies of our literature are available, please Sales Support Team can assist you with any document enquiries – 1300 200 004.
